1771-IFE A 1771-IFEA Allen Bradley modul input analog 12 BIT
Spesifikasi Produk
Merek / Pabrikan | Allen Bradley/AMERIKA SERIKAT |
Nomor bagian |
1771-IVN / C |
Nomor Bagian Alternatif | 1771-IVN / C |
Deskripsi |
modul input |
Dimensi | 15,2 cm x 5,1 cm x 27,9 cm |
Bobot | 0.40kg |
Rincian Produk
The 1771-IVN Series C dc input module is a source input and requires a sink output. Modul input dc 1771-IVN Seri C adalah input sumber dan membutuhkan output sink. A source input provides a positive voltage path and a sink output provides a path to ground. Input sumber menyediakan jalur voltase positif dan output sink menyediakan jalur ke ground.
Spesifikasi
nput per Modul: 16
Lokasi Modul: Semua sasis I / O 1771 kecuali 1771-A1, -A2, dan -A4
Rentang Tegangan Input: 10 hingga 30V dc
Minimum Input Current: 4.5mA at 10V dc; Input Minimum Saat Ini: 4.5mA pada 10V dc; 15mA at 30V dc 15mA pada 30V dc
Minimum Off-state Saat Ini: 2.0mA @ 5V dc
Tegangan Off-state Maksimum: 5V dc
Minimum On-state Voltage: 10V dc
Impedansi Input: maksimum 2.2K ohm
Input Signal Delay: delay propagasi Rendah ke Tinggi - 1ms Tinggi ke delay propagasi dapat dipilih - 1ms atau 6ms
Pembuangan Daya: 7,3 Watt (maks.), 1,0 Watt (min.)
Pembuangan Panas: 24,7 BTU / jam (maks.), 3,4 BTU / jam (min.)
Arus Balik: 130mA @ 5V dc + 5%
Tegangan Isolasi: Isolasi ini memenuhi atau melampaui persyaratan Standar UL 508, dan Standar CSA C22.2 No. 142.
Suhu Operasional: 0o hingga 60oC (32o hingga 140oF)
Suhu Penyimpanan: -40o hingga 85oC (-40o hingga 185oF)
Kelembaban Relatif: 5 hingga 95% (tanpa kondensasi)
Keying: Between 10 and 12; Keying: Antara 10 dan 12; Between 16 and 18 Antara 16 dan 18
Field Wiring Arm Standard Cat. Field Wiring Arm Standard Cat. No. 1771-WH No. 1771-WH
Wiring Arm Screw Torque 7-9 inch-pound
Agency Certification (when product is marked): CSA certified; Lembaga Sertifikasi (ketika produk ditandai): CSA bersertifikat; CSA Class 1, Division 2, Groups A, B, C, D certified; CSA Kelas 1, Divisi 2, Grup A, B, C, D bersertifikat; UL listed; UL terdaftar; CE marked for all applicable directives CE ditandai untuk semua arahan yang berlaku
Persyaratan Daya
Your module receives its power through the 1771 I/O chassis backplane from the chassis power supply. Modul Anda menerima dayanya melalui backplane sasis I / O 1771 dari catu daya sasis. The module requires 130mA from the output of this supply. Modul ini membutuhkan 130mA dari output pasokan ini. To calculate the requirements Untuk menghitung persyaratan
for the backplane power supply, add 130mA to the power requirements of all other modules in the I/O chassis. untuk catu daya backplane, tambahkan 130mA ke persyaratan daya semua modul lainnya dalam sasis I / O. Calculating the requirements will prevent an overload to the chassis backplane Menghitung persyaratan akan mencegah kelebihan beban pada rangka belakang sasis
dan / atau catu daya backplane.
