⇒ Klik di sini untuk harga yang bagus 1747-L543
Merek / Pabrikan | AB / AS |
Nomor bagian | 1747-L543 |
Nomor Bagian Alternatif | 1747-L543 |
Deskripsi | SLC 5/04 Prosesor |
Dimensi | 11,4 cm x 8,9 cm x 4,6 cm |
Bobot | 0,5 kg |
Rincian Produk
The AB 1747-L543 is an SLC 500 SLC 5/04 processor that has maximum discrete input and output capacities of 4096 each. AB 1747-L543 adalah prosesor SLC 500 SLC 5/04 yang memiliki kapasitas input dan output diskrit maksimum masing-masing 4.096. It has a maximum of 480local analog I/O, as well as a user memory of 64K words, specifically 60K words for data and program and 4K words for data only. Ini memiliki maksimum 480lokal analog I / O, serta memori pengguna 64K kata, khususnya 60K kata untuk data dan program dan 4K kata untuk data saja. It also comes with a Flash EPROM backup memory and 107 programming instructions. Ini juga dilengkapi dengan memori cadangan Flash EPROM dan 107 instruksi pemrograman. The 64 KB RAM of the 1747-L543 processor is battery-backed. 64 KB RAM prosesor 1747-L543 didukung baterai. The I/O chassis of the 1747-L543 is a maximum of 3, and it has a maximum of 30 I/O module slots. Sasis I / O pada 1747-L543 adalah maksimum 3, dan memiliki maksimum 30 slot modul I / O. The communication ports present on this processor are a DH+ port and an RS-232 port. Port komunikasi yang ada pada prosesor ini adalah port DH + dan port RS-232. The 1747-L543 It also has status LEDs present for forced I/O, run, CPU fault, RS-232, and DH+. The 1747-L543 Ini juga memiliki status LED untuk paksa I / O, menjalankan, kesalahan CPU, RS-232, dan DH +.
Program scan time of the 1747-L543 processor is 0.9 milliseconds/K on average, its typical I/O scan time is 0.225 milliseconds, and bit execution is 0.37 µs. Waktu pemindaian program dari prosesor 1747-L543 rata-rata adalah 0,9 milidetik / K, waktu pemindaian I / O tipikal adalah 0,225 milidetik, dan eksekusi bit adalah 0,37 μs. It also has a program scan hold-up time after the loss of power between 20 milliseconds and 3 seconds, which is also dependent on the loading of the power supply. Ia juga memiliki program waktu penahanan pemindaian setelah kehilangan daya antara 20 milidetik dan 3 detik, yang juga tergantung pada pemuatan catu daya. The 1747-L543 also runs on backplane currents of 1 A at 5 Volts DC and of 125 mA at 24 Volts DC. The 1747-L543 juga berjalan pada arus backplane 1 A pada 5 Volt DC dan 125 mA pada 24 Volt DC. Its operating shock is 30 G, and it can withstand an acceleration of 2.5 G at 57 to 2000 Hertz and a displacement of 0.015 inches, peak-to-peak, at 5 to 57 Hertz. Syok operasinya adalah 30 G, dan dapat menahan akselerasi 2,5 G pada 57 hingga 2000 Hertz dan perpindahan 0,015 inci, puncak-ke-puncak, pada 5 hingga 57 Hertz. Its non-condensing relative humidity is between 5 and 95%, its storage temperature is -40 to 85 degrees Celsius, and its operating temperature is 0 to 60 degrees Celsius. Kelembaban relatif non-kondensasi antara 5 dan 95%, suhu penyimpanannya -40 hingga 85 derajat Celcius, dan suhu operasinya adalah 0 hingga 60 derajat Celcius.
